Automated Liquid Handling: Auflo-P1200, tap a thumbnail to see more views.
Automated Liquid Handling: Auflo-P1200
The Galatek Auflo-P1200 is a liquid handling workstation with 4 independent 1000 µl pipetting channels, each with its own adjustable volume and spacing, on a deck with 25 positions in a 30-grid layout. The pipetting range is 2 to 1000 µl. The deck takes SBS format plates in 96, 384, deep-well, ELISA and cell culture formats, PCR plates, blood collection tubes, centrifuge tubes and tip boxes.
Quote-based, no public pricing. Add to your quote and our specialists put together a proposal with the right documentation, typically within 24 hours.
This instrument in detail
- 4 independent 1000 µl channels, adjustable spacing and volume
- Pipetting range 2 to 1000 µl
- Precision 5.0 per cent CV at 2 µl, 3.0 per cent at 10 µl, 2.0 per cent at 50 µl
- Deck with 25 positions in a 30-grid layout, SBS format
- Drag-and-drop process editing, CSV and work list import
- 1100 x 770 x 820 mm, 110 kg
The Galatek Auflo-P1200 automates pipetting steps that are otherwise done by hand, with four channels that can each work at their own volume and spacing.
Pipetting
Four independent channels with a range of 2 to 1000 µl. The manufacturer states a precision of 5.0 per cent CV at 2 µl with a 10 µl tip, 3.0 per cent at 10 µl with a 10 µl tip and 2.0 per cent at 50 µl with a 200 µl tip. Because both the volume and the channel spacing are adjustable per channel, transfers between different labware formats do not need a fixed pitch.
Deck and labware
The deck offers 25 positions in a 30-grid layout and takes SBS format microplates in 96, 384, deep-well, ELISA and cell culture versions, PCR plates, blood collection tubes, centrifuge tubes, sample tubes, 8-strip tubes, loading slots and tip boxes.
Software and applications
Protocols are built by drag and drop, with import of CSV files and work lists and configurable liquid classes. Named application areas are genomics, cell biology, drug discovery, synthetic biology, proteomics, biopharmaceuticals and clinical diagnostics. Dimensions are 1100 mm wide, 770 mm deep and 820 mm high, weight 110 kg.
- Dimensions: 1200 mm × 770 mm × 970 mm
- Weight: 110 kg
- Rated Power: 300 W
- Operating Temperature: 15°C – 32°C
- Humidity Range: 30% – 80% (non-condensing)
